FRAME
All New Series 2 6061 Aluminum, Double Butted Frame, Internal Cable Routing, 141mm Open Dropout, 73mm Threaded BB
FRONT SUSPENSION
SR Suntour XCM34 Boost 15x110mm Spacing, 130mm Travel, Coil Spring, 27.5", Bolt-On Thru-Axle
RIMS
Marin Aluminum Double Wall, Disc Specific, 29mm Inner, Pinned Joint, 32H, Tubeless Compatible
HUB, REAR
Forged Alloy, Quad Sealed Cartridge Bearings, Alloy Axle, QR type, 141mm Width, Disc, 32H, Shimano Standard Freehub Body
HUB, FRONT
Forged Alloy, 110x15mm, Sealed Cartridge Bearing, Disc, 32H
SPOKE, NIPPLES
14g Black Stainless Steel
TIRES
Vee Tire Co, Flow Snap, 27.5x2.6", MPC Compound, Wire Bead
DERAILLEUR, REAR
MicroShift RD-M9195M, 9 Speed, With Clutch
DERAILLEUR, FRONT
-
SHIFT LEVER
MicroShift SL-M9195-R, 1x9 with Bearings
CRANKSET
Marin Forged Alloy, Integrated Steel 32T Narrow Wide Chainring, Boost Spacing
BOTTOM BRACKET
Sealed Cartridge Bearing, Square Taper
CHAIN
KMC X-9
CASSETTE
Sunrace, 9 Speed, 11-46T
BRAKE, FRONT
Tektro M275 Hydraulic Disc Brake, 180mm Rotor
BRAKE, REAR
Tektro M275 Hydraulic Disc Brake, 180mm Rotor
BRAKE LEVERS
Tektro M275 Hydraulic Disc
HANDLEBAR
Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back
STEM
Marin Alloy, 45mm
GRIPS
Marin MTN, Closed End
HEADSET
FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
SEATPOST
Marin Alloy, 30.9mm
SADDLE
Marin Speed Concept
PEDALS
Nylon Platform
EXTRAS
-
