FRAME
Series 3 Double Butted and Formed CrMo tubing, Integrated Drop-In Headset, External Rear Derailleur and Brake Housing, Internal Dropper Post Routing, 148x12mm Boost Rear Spacing, Post Mount Brake Mounts
FRONT SUSPENSION
Marzocchi Z1, 140mm Travel, EVOL Air Spring, GRIP Damper w/ Sweep Adjust, Kabolt 110 Axle, 44mm Offset
RIMS
Marin, Double Wall Alloy, 29mm Inner, Welded Joint, Disc Specific, 32H, Tubeless Compatible
HUB, REAR
Shimano HB-MT410B, 148x12mm, Disc, Microspline Freehub Body
HUB, FRONT
Shimano HF-MT410B, 110x15mm, Disc
SPOKE, NIPPLES
14g Black Stainless Steel
TIRES
Maxxis Assegai 29x2.5", 3C MAXX GRIP EXO+ Front, 3C MAXX TERRA Double Down Rear, Tubeless Compatible
DERAILLEUR, REAR
Shimano Deore, 12-Speed, SGS
DERAILLEUR, FRONT
-
SHIFT LEVER
Shimano Deore, M6100, 12-Speed
CRANKSET
FSA Comet, Modular 1x, 32T Direct Mount Chainring, MegaTooth Technology, Boost Spacing
BOTTOM BRACKET
Mego EXO 73mm BSA
CHAIN
KMC X-12 Silver and Black
CASSETTE
Shimano, Deore 12-Speed, 10-51T
BRAKE, FRONT
Shimano BR-MT420, 4-Piston Hydraulic Disc Brake, 203mm Rotor
BRAKE, REAR
Shimano BR-MT420, 4-Piston Hydraulic Disc Brake, 180mm Rotor
BRAKE LEVERS
Shimano BL-M4100 Hydraulic Lever, I-Spec EV Compatible
HANDLEBAR
Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back
STEM
Marin 3D Forged Alloy, 35mm
GRIPS
Marin Grizzly, Lock On
HEADSET
FSA Orbit 40 No.42 ACB
SEATPOST
X Fusion Manic, Regular = 150mm Travel, Grande = 170mm Travel
SADDLE
Marin Speed Concept
PEDALS
-
EXTRAS
Bolt-On Thru-Axle
