Specifications:
Frame
All New Series 4 Alloy Lightweight E Frame, 140mm MultiTrac Suspension, Integrated Battery/Charging Port, 148mm Rear Thru-Axle
Front Suspension
Fox 36 Performance, 150mm Travel, 29", 110x15 Kabolt, 44mm Offset
Rear Suspension
Fox Float X, Performance, EVOL Air Spring, Climb Switch, Rebound Adjustment, Custom Tune, 210x55mm, 25xM8 Upper Mount, 25xM8 Upper & Lower Mount
Rim
Marin Aluminum Double Wall, 29" Diameter, 32mm Inner Rim Width, Pinned Joint, Disc Specific, Tubeless Compatible
Hub Rear
Formula DC-711, 110x15, 6-Bolt, 32H
Hub Front
Formula DCL-3482, 4 Sealed Bearings, 148x12, XD Driver, 6-Bolt, 32H
Spokes
14g Black Stainless Steel
Tires
Front: Maxxis Minion DHF, 29x2.4" MAXXGRIP, Tubeless ready, EXO+, Rear: Maxxis Forecaster 29x2.4", Tubeless Ready MAXX TERRA EXO+
Derailleur Rear
SRAM GX Eagle Lunar
Derailleur Front
-
Shift Lever
SRAM GX Eagle Lunar MMX Mount
Crankset
e*thirteen e*spec Plus, 160mm Length, 34T
Motor
Bosch Performance Line SX, 600W, 55Nm torque, 20MPH Top Assisted Speed
Chain
SRAM NX Eagle
Cassette
SRAM XG 1275 Eagle Cassette 10-52T
Brakes Front
SRAM Code Bronze, 4-Piston Hydraulic Disc, 200mm HS2 Rotor
Brakes Rear
SRAM Code Bronze, 4-Piston Hydraulic Disc, 200mm HS2 Rotor
Brake Levers
SRAM Code Bronze Stealth
Handlebar
Marin Trail, 35mm Clamp, 7000 Alloy Bar, 800mm Length, 20mm Rise, 5 Degree Up, 8 Degree Back
Stem
Marin CNC, 35mm Length, 35mm Bar Bore
Grips
Marin Grizzly Lock On
Headset
FSA Custom, Adjustable HTA Design
Seatpost
TranzX, YSP39 1x Remote, 34.9 Seatpost Diameter, Travel S = 150mm, M/L = 170mm, XL = 200mm
Saddle
Marin Speed Concept
Pedals
Marin MTB Plastic
Battery
Bosch 400 Wh Internal (Optional PowerMore 250 wh external battery using PowerMore 150mm cable EB12.120.036)
Display
Bosch BRC3100 Systems Controller
Switch
Bosch BRC3300 Bluetooth Remote 22.2mm Clamp
Extras
e*thirteen e*Spec Chainguide
Extras
Bolt-On 12mm Thru-Axle, 174mm Length, 1.0 Thread Pitch, 16.5mm, Tapered Head, Bosch EB12.110.016; 2A Charger
Range, Charging Time
15-55 miles (Based on Rider Weight, Terrain, Climate and Level of Assist Used), 6 Hours (estimated, under ideal conditions)
