Frame
Series 4 Alloy Frame, 150mm MultiTrac Suspension, Integrated Battery/Charging Port, 148mm Rear Thru-Axle, Built-in Rear Speed Sensor
Fork
Fox 38 Performance Elite, 160mm travel, 29" , 110x15mm Boost Kabolt Thru-Axle, 44mm Offset, Integrated Fox Fender
Shock
Fox DHX2, Performance Elite, Low Speed Compression and Rebound Adjustment, 205x65mm, Trunnion Upper Mount, 25mmxM8 Lower Mount, S/M Spring Rate = 350lb, L/XL Spring Rate = 450lb
Rims
Front: Marin Aluminum Double Wall, 29" Diameter, 32mm Inner Rim Width, Sleeved Joint, Disc Specific, Tubeless Compatible; Rear: Marin Aluminum Double Wall, 27.5" Diameter, 38mm Inner Rim Width, Sleeved Joint, Disc Specific, Tubeless Compatible
Hub Rear
Forged Aluminum, 148x12mm, Disc, 32H
Hub Front
Forged Aluminum, 148x12mm, Disc, 32H
Spokes
14g Black Stainless Steel
Tires
Front: Vee Tire Co. Attack HPL, 29x2.5", Top 40 Tubeless Compatible, Rear: Vee Tire Co. Crown Gem, 27.5x2.8”, TACKEE Compound, Tubeless Compatible
Derailleur Rear
Shimano XT 12-Speed, SGS
Shift Lever
Shimano SLX 12-Speed, I-Spec EV
Crankset
Shimano XT M8150, 160mm Length, 38t Chainring
Motor
Shimano Steps EP801 Drive Unit, 250W, 85Nm
Chain
KMC E12S, eMTB-Specific Chain
Cassette
SunRace 12-speed, 11-51
Brakes Front
TRP DH-R Evo, 4-Piston Hydraulic Disc, Metallic Pads, 203mm Rotor
Brakes Rear
TRP DH-R Evo, 4-Piston Hydraulic Disc, Metallic Pads, 203mm Rotor w/ Speed Sensor
Brake Levers
TRP DH-R Evo
Handlebar
Marin Trail Bar, 35mm Clamp, 7000 Alloy Bar, 800mm Length, 20mm Rise, 5 Degree Up, 8 Degree Back
Stem
Marin CNC, 35mm Length, 35mm Bar Bore
Grips
Marin Grizzly Lock On
Headset
FSA No 57, Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
Seatpost
X-Fusion Manic, 1x Composite Remote, Size S 125mm Travel, Size M and L 150mm Travel, Size XL 170mm Travel, 30.9mm
Saddle
Marin eMTB Saddle
Pedals
Marin MTB Plastic
Battery
BT-8036, Internal 630Wh
Display
Shimano SC-E600
Switch
SW-EN600L Left Hand Switch for Assist Mode Change
Extras
Shimano Battery Charger EC-E6002, Shimano CS-EN800 Chainguide, CushCore, 29" Pro Front, Plus Rear, with CushCore Valve Stems, Marin Tire Sealant 250ml, Squeeze Top with Valve Core Removal Tool Cap
